3G | Y |
4G | Y |
4G bands supported | 800,900,1800,1900,2100,2300,2500,2600 MHz |
AC adapter included | Y |
Antenna connector type | N-type |
Antennas quantity | 2 |
Browser supported | Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0 |
Cables included | LAN (RJ-45) |
Cabling technology | 10/100Base-T(X) |
Certification | CE, RoHS |
DC-in jack | Y |
Depth | 114 mm |
DHCP client | Y |
DHCP server | Y |
DMZ support | Y |
Ethernet LAN | Y |
Ethernet LAN (RJ-45) ports | 2 |
Ethernet LAN data rates | 10,100 Mbit/s |
Firewall | Y |
Firmware upgradeable | Y |
Height | 36 mm |
IP address filtering | Y |
Linux operating systems supported | Y |
MAC address filtering | Y |
Mac operating systems supported | Y |
Networking standards | IEEE 802.11b,IEEE 802.11g,IEEE 802.11n |
On/off switch | Y |
Operating relative humidity (H-H) | 10 - 90 % |
Operating temperature (T-T) | 0 - 40 °C |
Output current | 0.85 A |
Output voltage | 9 V |
Package depth | 161 mm |
Package height | 66 mm |
Package weight | 450 g |
Package width | 293 mm |
Port forwarding | Y |
Power source type | DC |
Product type | Tabletop router |
Quality of Service (QoS) support | Y |
Quick installation guide | Y |
Receiver sensitivity | 11g 54M: -74dBm 11n HT20: -71dBm 11n HT40: -67dBm |
Reset button | Y |
Security algorithms | 64-bit WEP,128-bit WEP,WPA,WPA-PSK,WPA2,WPA2-PSK |
Storage relative humidity (H-H) | 5 - 90 % |
Storage temperature (T-T) | -40 - 70 °C |
Supported network protocols | IPv4, IPv6 |
UMTS bands supported | 850,900,2100 MHz |
Universal Plug and Play (UPnP) | Y |
USB port | N |
Wi-Fi standards | 802.11b,802.11g,Wi-Fi 4 (802.11n) |
Width | 154 mm |
Windows operating systems supported | Windows 2000,Windows 7,Windows 8,Windows 8.1,Windows 98SE,Windows NT,Windows Vista,Windows XP |
WPS push button | Y |
Stateful Packet Inspection (SPI) | Y |
Wireless radio | Y |
Wireless statistics | Y |
Port triggering | Y |
Mobile network generation | 4G |
Harmonized System (HS) code | 85176990 |
Antenna design | External |
Schedule access | Y |
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11n) | 20 dBmW |
Wi-Fi Multimedia (WMM)/(WME) | Y |
2.4 GHz, 300 Mbps, IEEE 802.11b/g/n, 10/100Mbps LAN RJ-45, 10/100Mbps LAN/WAN RJ-45, 1x Nano SIM, 154×114×36 mm
