HomeAPC Rack PDU, Basic, 1U, 30A, 120V
APC Rack PDU, Basic, 1U, 30A, 120V
  • APC Rack PDU, Basic, 1U, 30A, 120V
  • APC Rack PDU, Basic, 1U, 30A, 120V
19 inch Rack-Mountable Supplies redundant AC power to connected equipment. Two AC lines power the unit and if the primary AC power fails, the unit will automatically switch to the alternate power source.Resettable circuit breakers Enables a quick recovery from overload events. Vertical mounting capability. Horizontal mounting capability.
AC input frequency50 - 60 Hz
Cable length3.66 m
Dimensions (WxDxH)447 x 57 x 44 mm
Input connection typeNEMA L5-30P
Load capacity2880 VA
Maximum input current per phase30 A
Maximum total current draw per phase24 A
Nominal input voltage120 V
Nominal output voltage120 V
Operating temperature (T-T)-15 - 45 °C
Output connections10x NEMA 5-20R
Storage temperature (T-T)-25 - 65 °C
Weight2500 g

APC Rack PDU, Basic, 1U, 30A, 120V

Basic Rack PDU , Input: 120V , Input Connections: NEMA L5-30P , Cord Length: 12 feet ( 3.66 meters ) , Output: 120V , Output Connections: NEMA 5-20R

AP9560

Out of Stock

£258.06
£215.05 Ex VAT.
